Overview
msystems' mSSD SATA 2.5" (formerly Fast
Flash Disk (FFD) 2.5" Serial ATA) Flash Disk is a
state-of-the-art solid-state disk, based on NAND
flash technology, that provides the functionality of
a hard disk with no moving parts. mSSD SATA 2.5”
Flash Disk is an ideal, reliable storage solution
for telecommunication and blade servers industry
that must support 99.999% availability and comply
with NEBS Level 3.
mSSD SATA 2.5” Flash Disk delivers outstanding
reliability and enhanced endurance thanks to
msystems' TrueFFS technology, which applies dynamic
wear-leveling and bad block management. Due to its
unique design, mSSD SATA 2.5” Flash Disk provides
high-performance sustained read and write rates up
to 150MB/s and supports Serial ATA 1.0a standard.
mSSD SATA 2.5” Flash Disk is fully compatible
with the SATA 1.0a interface, and has the same
mechanical dimensions and mounting holes of
traditional mechanical disks. It is a true drop-in
replacement for rotating 2.5" Serial ATA (SATA) and
Serial Attached SCSI (SAS) disks with highest
reliability and operating MTBF hours.
msystems' mSSD family has been providing rugged,
mass storage solutions to an expansive range of
industries since 1997. In air force, navy and army
installations, it has been field-tested inside data
recorders, moving maps, sonar, radar, fire control
systems, black boxes, data acquisition systems,
C4ISR, telecommunications, rugged laptops, tablet
PCs and servers.
Specifications
Capacity
Unformatted (GBytes): 1, 2, 4, 8, 12, 16,
24, 32, 40, 48, 56, 64, 72, 80, 88, 96, 104, 112,
120, 128
Compatibility
Serial ATA: High-speed serialized AT
attachment, revision1.0a, Serial ATA working group
Performance
Burst Read/Write: 150 MBytes/sec (1.5
Gbits/sec)
Sustained Read: 44 MBytes/sec
Sustained Write: 40 MBytes/sec
Access time: <0.04 ms
Physical
Form factor: 2.5"
Case dimensions (mm): 100.2(L) X 69.85(W) X 9.5 to
22.5(H)
Weight: 0.1 Kg for 16GB; 0.22 Kg for 128GB
Environmental
Operating temperature
Commercial: 0°C to +70°C
Enhanced: -25°C to +75°C
Extended: -40°C to +85°C
Storage temperature: -55°C to +95°C
Humidity: 5% to 95% relative, non-condensing
Operating altitude: Up to 80,000 feet
Operating shock: 1,500G, MIL-STD-810F
Operating vibration:16.3G RMS (random, 10Hz to
2000Hz;3 vibration axes), MIL-STD-810F
Power
Input voltage: 5VDC (+/- 5%)
Typical power consumption:
16GB 128GB
Idle 1.8 W 2.2 W
Sustained read/write 2.3 W 2.9 W
Sanitize 2.4 W 6.2 W
Reliability
MTBF: 1,180,777operating hours MTBF for
16GB based on Telcordia SR-332, GB, 25°C
EDC/ECC: Embedded EDC/ECC, based on BCH Algorithm
BER (Bit Error Rate) <10-20
Reliability features
Built-in power-up self-test (BIT)
Manual and automatic self-diagnostics
TrueFFS bad block management
Data integrity under power-cycling
SMART (Self-Monitoring, Analysis and Reporting
Technology) remote monitoring
Endurance
Unlimited read cycles
>5,000,000 Write/Erase cycles
TrueFFS dynamic wear-leveling
Garbage collection process
>10 years data retention
User Interface & Configuration
Interface: SATA 1.5 Gbits/sec
Firmware upgrade: Field upgrade capability
Format: Factory low-level format
Drivers: None required
Power LED: Green
Access LED: Red
Enhanced Security Erase
Entire disk security erase in seconds
Partial security erase
Auto-resume security erase/sanitize on power
interrupt
Sanitize complies with NISPOM DoD 5220.22-M, NSA
130-2, Air Force AFSSI 5020, Army 380-19, Navy NAVSO
P-5239-26 and IREC (IRIG) 106 NTISSP-9
Secure erase/sanitize software interrupt, hardware
interrupt optional
RoHS Compliant
The product is available in RoHS (Pb-free) and Pb
(Leaded) versions.
Compliance
CE, UL, EN 55022 Class B, CISPR 22 Class B,
AS/NZS 3548 Class B, BSMI CNS 13438 Class B,
CAN/CSA-V-3/2001.04 (VCCI), FCC Part 15 Class B, EN
61000-3-2, EN 61000-3-3, IEC 61000-4-2/3/4/5/6/8/11,
MIL-STD-810F
Customization
PCB conformal coating
Faster read/write rates
Made in the USA
Supports FMF requirements
Warranty
5 years (longer warranty period can be supported)
Ordering Information
FFD-25-SATA-CCC-T-H
CCC - Unformatted capacity (GB): 1, 2, 4,
8, 12, 16, 24, 32, 40, 48, 56, 64, 72, 80, 88, 96,
104, 112, 120, 128
T:Operating temperature range
Blank - Commercial: 0°C to +70°C
N - Enhanced: -25°C to +75°C
X - Extended: -40°C to +85°C
H:Case Height
A - 9.5mm up to 16GB
B - 14.5mm up to 64GB
C - 18.5 mm up to 112GB
D - 22.5 mm up to 128GB
P:RoHS Compatibility
Blank - Non RoHS version
P - RoHS version
