1、Mini-Circuits产品图文介绍 2、Mini-Circuits库存 3、Mini-Circuits 详细资料下栽4、Mini-Circuits应用资料

5、MINI详细产品资料介绍

低通滤波器(LFCN)系列 高通滤波器(HFCN)系列 放大器 开关 表面贴装(Surface Mount) 插件(Plug-in)

单片增益放大器(Monolithic Gain Block)

产品型号

频率范围
(MHz)

Gain (dB)
Typ.

Max. Power
Output @
1 dB comp.
(dBm)
Typ.

N.F. (dB)
Typ.

IP3
(dBm)
Typ.

VSWR (:1)
Typ.

Device DC Operating Power

Low

High

In

Out

Voltage
(V)

Current(mA)

(+) 符号表示无铅环保产品

ERA-1+

DC

8000

10.9

12.0

4.3

26.0

1.5

1.5

3.4

40

ERA-2+

DC

6000

14.4

13.0

4.0

26.0

1.3

1.2

3.4

40

ERA-3+

DC

3000

18.7

12.5

3.5

25.0

1.5

1.4

3.2

35

ERA-4+

DC

4000

13.4

17.3

4.2

34.0

1.2

1.3

4.5

65

ERA-5+

DC

4000

18.5

18.4

4.3

32.5

1.3

1.2

4.9

65

ERA-6+

DC

4000

12.2

17.9

4.5

36.0

1.3

1.6

5.0

70

ERA-1SM+

DC

8000

10.9

12.0

4.3

26.0

1.5

1.5

3.4

40

ERA-2SM+

DC

6000

14.4

13.0

4.0

26.0

1.3

1.2

3.4

40

ERA-21SM+

DC

8000

12.2

12.6

4.7

26.0

1.1

1.3

3.5

40

ERA-3SM+

DC

3000

18.7

12.5

3.5

25.0

1.5

1.4

3.2

35

ERA-33SM+

DC

3000

17.4

13.5

3.9

28.5

1.6

1.25

4.3

40

ERA-4SM+

DC

4000

13.4

17.3

4.2

34.0

1.2

1.3

4.5

65

ERA-4XSM+

DC

4000

13.5

17.0

4.2

35.0

1.3

1.3

4.5

65

ERA-5SM+

DC

4000

17.6

18.4

4.3

32.5

1.3

1.2

4.9

65

ERA-5XSM+

DC

4000

17.6

17.8

3.5

33.0

1.3

1.3

4.9

65

ERA-50SM+

DC

2000

19.4

17.2

3.5

32.5

1.3

1.2

4.4

60

ERA-51SM+

DC

4000

16.1

18.1

4.1

33.0

1.1

1.2

4.5

65

ERA-6SM+

DC

4000

12.2

17.9

4.5

36.0

1.3

1.6

5.0

70

ERA-8SM+

DC

2000

19.0

12.5

3.1

25.0

1.4

1.8

3.7

36

GALI-1+

DC

8000

11.8

10.5

4.5

27.0

1.3

1.4

3.4

40

GALI-19+

DC

7000

11.6

9.0

6.5

23.7

1.6

1.5

3.6

40

GALI-2+

DC

8000

14.8

11.0

4.6

27.0

1.6

1.6

3.5

40

GALI-21+

DC

8000

13.1

10.5

4.0

27.0

1.1

1.3

3.5

40

GALI-24+

DC

6000

16.6

19.3

4.3

35.3

1.4

2.0

5.8

80

GALI-29+

DC

7000

19.7

10.0

6.0

24.7

1.5

1.5

3.6

40

GALI-3+

DC

3000

19.1

10.5

3.5

25.0

1.5

1.2

3.3

35

GALI-33+

DC

4000

17.5

11.4

3.9

28.0

1.6

1.2

4.3

40

GALI-39+

DC

7000

19.7

9.0

2.4

22.9

1.6

1.5

3.5

35

GALI-4+

DC

4000

13.5

16.0

4.0

34.0

1.2

1.4

4.6

65

GALI-4F+

DC

4000

13.4

13.8

4.0

32.0

1.2

1.5

4.4

50

GALI-49+

DC

5000

13.6

15.0

5.5

33.3

1.7

1.5

5.0

65

GALI-5+

DC

4000

17.5

16.0

3.5

35.0

1.2

1.4

4.4

65

GALI-5F+

DC

4000

17.4

14.2

3.5

31.5

1.2

1.4

4.3

50

GALI-51+

DC

4000

16.1

16.5

3.5

35.0

1.3

1.5

4.5

65

GALI-51F+

DC

4000

15.9

14.4

3.5

32.0

1.2

1.5

4.4

50

GALI-52+

DC

2000

17.8

15.5

2.7

32.0

1.35

1.4

4.4

50

GALI-55+

DC

4000

18.5

15.5

3.3

28.5

1.25

1.3

4.3

50

GALI-59+

DC

5000

18.3

17.6

4.3

33.3

1.6

1.5

4.8

65

GALI-6+

DC

4000

11.3

18.2

4.5

35.5

1.5

1.8

5.0

70

GALI-6F+

DC

4000

11.6

15.8

4.5

35.5

1.5

1.9

4.8

50

GALI-74+

DC

1000

21.8

18.3

2.7

38.0

1.2

1.6

4.8

80

GALI-84+

DC

6000

16.7

21.0

4.4

37.4

1.4

2.1

5.8

100

GALI-S66+

DC

3000

17.3

2.8

2.7

18.0

1.25

1.7

3.5

16

GVA-84+

DC

6000

16.0

20.6

5.5

35.8

1.3

2.6

5.0

108

LEE-19+

DC

8000

12.0

10.2

6.5

24.5

1.5

1.4

3.6

40

LEE-29+

DC

8000

15.4

10.9

5.5

25.5

1.4

1.3

3.6

40

LEE-39+

DC

8000

20.8

10.4

2.4

23.4

1.3

1.3

3.5

35

LEE-49+

DC

5000

14.0

16.4

5.5

33.0

1.6

1.4

4.9

65

LEE-59+

DC

5000

19.7

17.3

4.5

33.0

1.5

1.5

4.8

65

MAR-1+

DC

1000

16.5

2.5

3.5

14.0

1.3

1.2

5.0

17

MAR-1SM+

DC

1000

16.5

2.5

3.3

14.0

1.3

1.2

5.0

17

MAR-2SM+

DC

2000

12.0

7.0

3.7

22.0

1.3

1.3

5.0

25

MAR-3+

DC

2000

12.0

10.0

6.0

23.0

1.5

1.7

5.0

35

MAR-3SM+

DC

2000

12.0

10.0

3.7

28.0

1.3

1.3

5.0

35

MAR-4+

DC

1000

8.0

12.5

7.0

25.5

1.5

1.9

5.25

50

MAR-4SM+

DC

1000

8.0

12.5

6.0

25.5

1.6

2.0

5.3

50

MAR-6+

DC

2000

20.0

3.0

3.0

14.5

1.7

1.7

3.5

16

MAR-6SM+

DC

2000

20.0

3.0

3.0

14.5

1.3

1.3

3.5

16

MAR-7SM+

DC

2000

12.5

3.5

5.0

19.0

1.3

1.3

4.0

22

MAR-8A+

DC

1000

25.0

12.5

3.1

25.0

1.4

1.8

3.7

36

MAR-8ASM+

DC

1000

25.0

12.5

3.1

25.0

1.4

1.8

3.7

36

MAR-8SM+

DC

1000

22.5

12.5

3.3

27.0

3.1

3.1

7.8

36

MAV-11SM+

50

1000

10.5

17.5

3.6

30.0

1.5

1.7

5.5

60

MAV-11BSM+

50

1000

11.3

18.0

4.4

34.0

1.2

1.2

5.5

60

MNA-2

500

2500

12.8

17.7

5.4

28.0

1.5

1.6

2.8 to 5.0

76

MNA-3+

500

2500

16.1

11.4

4.9

21.3

1.9

1.5

2.8 to 5.0

30

MNA-4+

500

2500

16.4

19.0

4.8

29.0

1.5

1.7

2.8 to 5.0

75

MNA-5+

500

2500

21.9

12.2

3.5

21.0

1.6

1.9

2.8 to 5.0

28

MNA-6+

500

2500

23.6

18.0

2.9

28.0

1.5

1.6

2.8 to 5.0

81

MNA-7+

1500

5900

17.4

15.9

6.9

28.6

2.0

1.5

2.8 to 5.0

73

RAM-1+

DC

1000

15.5

1.5

5.5

14.0

1.3

1.3

5.0

17

RAM-2+

DC

2000

11.8

4.5

6.5

17.0

1.2

1.4

5.0

25

RAM-3+

DC

2000

12.0

10.0

6.0

23.0

1.6

1.7

5.0

35

RAM-4+

DC

1000

8.0

12.5

6.5

25.5

1.4

1.9

5.3

50

RAM-6+

DC

2000

16.0

2.0

2.8

14.5

1.4

1.3

3.5

16

RAM-7+

DC

2000

12.5

5.5

4.5

19.0

2.0

1.8

4.0

22

RAM-8+

DC

1000

23.0

12.5

3.0

27.0

3.1

3.1

7.8

36

VAM-3+

DC

2000

11.0

9.0

6.0

22.0

1.5

1.7

4.7

35

VAM-6+

DC

2000

15.0

2.0

3.0

14.0

1.6

1.5

3.3

16

VAM-7+

DC

2000

12.0

5.5

5.0

18.0

1.5

1.5

3.8

22

VNA-22

500

2500

13.8

17.0

6.7

29.0

1.6

1.4

5.0

80

VNA-23

500

2500

18.3

10.0

4.7

21.0

1.5

1.3

5.0

32

VNA-25+

500

2500

18.6

18.2

5.5

29.0

1.5

1.6

5.0

85

VNA-28

500

2500

22.8

11.0

3.7

22.0

1.6

1.6

5.0

33

匹配单片双晶体(Dual Matched Monolithic)

产品型号

Freq.
(GHz)
DC to

Gain (dB)
Typ.

Max.
Power
(@ 1 dB Comp.)
(dBm)

NF
(dB)
Typ.

IP3
(dBm)
Typ.


VSWR
(:1)
Typ.


DC Operating
Power
Pin 5, Pin 8

Thermal
Resistance
θjc. Typ. ℃/W

Matching

Amplitude
Unbalance
between
2 amps (dB)

Phase
Unbalance
between
2 amps (deg.)

In

Out

Current
(mA)

Voltage
Typ.

DC-2.2 GHz.
Typ.

2.2-4 GHz
Typ.

DC-2.2 GHz.
Typ

2.2-4 GHz
Typ.

(+) 符号表示无铅环保产品

MERA-533+

4.0

18.8

17.5

3.5

33

1.4

1.5

65

4.9

133

0.05

0.1

0.7

2.0

MERA-556+

2.2

19.0

17.6

3.5

35.5

1.2

1.4

65

4.9

133

0.10

0.1

0.6

1.5

MERA-7433+

1.0

19.0

18.3

2.7

35

1.25

1.8

80

4.8

120

0.15

0.3

0.5

1.0

MERA-7456+

1.0

18.6

18.2

2.7

35

1.3

2.0

80

4.8

120

0.05

0.1

0.7

2.0

高IP3(High IP3)

包装号 *

频率范围
(MHz)

Ohms(Ω)

Gain
(dB)

最大功率 (dBm)

NF
(dB)

IP3
(dBm)

VSWR (:1)
Typ.

DC
Power

Min.

Typ.

Max.

Typ.
Flatness

Output

Input

In

Out

Volt
Typ.

Current
ma

(+) 符号表示无铅环保产品

HELA-10A (+)

50

1000

75

10.0

12.0

13.0

±0.4

30

20

3.5

47

1.22

1.22

12

525

HELA-10B (+)

50

1000

50

9.5

12.0

13.0

±0.4

30

20

3.5

47

1.22

1.22

12

525

HELA-10C (+)

5

450

75

9.3

11.4

12.5

±0.4

30

20

3.5

48

1.30

1.22

12

525

HELA-10D (+)

8

300

50

9.3

11.0

12.5

±0.4

30

20

3.5

48

1.20

1.20

12

525

* 一个包装中包含有1个 HELA-10和2个变压器.

低噪声型号(Low Noise Moduls)


产品型号

频率范围
(MHz)

Gain (dB)
Typ.

Max. Power
Output @
1 dB comp.
(dBm)
Typ.

N.F. (dB)
Typ.

IP3
(dBm)
Typ.

VSWR (:1)
Typ.

Device DC Operating Power

In

Out

Voltage
(V)

Current(mA)

(+) 符号表示无铅环保产品

TAMP-960LN+

824

960

18

16.5

0.55

30.0

1.1

1.4

5.0

45
