package	data sheet	FAX
[TQFP-48]	pdf	12310



>75 dB RSSI range
Internal data slicer; 0.3V max logic "0", Vccx-0.3V min logic "1"
Total supply current
RX mode:	27 mA max, 21 mA typ
PLL mode:	20 mA max, 16 mA typ
TX flywheel mode:	11.5 mA max, 9 mA typ
Standby mode:	100 microamps max
Mixer power gain from IP1 to IF1, external load impedance of 600 ohms: 8 dB typ
On-chip LO generation, including VCO, prescalers, and phase/frequency detector
Supports reference crystal frequencies of 9, 12, and 16 times the DECT bit rate of 1.152 MHz
IF input frequency range up to 250 MHz
